Drink container and leak proof plug lid for use therewith

Field of invention

The present invention relates to drink containers and removable lids for use therewith, and more precisely to plug lids.

Background

Drink containers or drinking vessels with lids having sealing mechanisms are known in the art. Many require the lid to be threadably attached to a drink container body. One disadvantage of threadably attached lids is the time, effort and motion required to attach or remove the lid from the drink container body, and also the difficulty of doing so in some situations. Known plug lids overcome some of these issues, but generally do not permit drinking from the drinking container unless the plug lid is fully removed from the drinking container. A sealing problem exists with some plug lid designs when used with drink container bodies having variations in the interior diameter of the bodies, thus requiring a lid with a wide size tolerance to insure a good fluid-tight seal with the interior wall of the container body.

Brief description of the drawings

FIG. 1 is a top perspective view of a drink container with a plug lid in a first operational position.

FIG. 1A is a top plan view of the drink container of FIG. 1 .

FIG. 1B is a cross-sectional view of the drink container of FIG. 1 taken substantially along the line 1 B- 1 B of FIG. 1A .

FIG. 1C is a partial enlargement of FIG. 1B .

FIG. 2 is a top perspective view of the drink container of FIG. 1 with the plug lid in a second operational position.

FIG. 2A is a top plan view of the drink container of FIG. 2 .

FIG. 2B is a cross-sectional view of the drink container of FIG. 2 taken substantially along the line 2 B- 2 B of FIG. 2A .

FIG. 2C is a partial enlargement of FIG. 2B .

FIG. 3 is a top perspective view of the drink container lid of FIG. 1 with the plug lid in a third operational position.

FIG. 3A is a top plan view of the drink container lid of FIG. 3 .

FIG. 3B is a cross-sectional view of the drink container lid of FIG. 3 taken substantially along the line 3 B- 3 B of FIG. 3A .

FIG. 3C is a partial enlargement of FIG. 3B .

FIG. 4 is a top perspective view of the drink container of FIG. 1 with the plug lid in the third operational position shown in FIG. 3 and removed from a body of the drinking container.

FIG. 5 is a left side elevational view of the drink container of FIG. 4 .

FIG. 6 is a top perspective exploded view of the drink container of FIG. 1 .

FIG. 7 is a rear elevational exploded view of the drink container of FIG. 1 .

FIG. 8 is a left side elevational exploded view of the drinking container of FIG. 1 .

FIG. 9 is a top perspective view of a drink container with a second embodiment of the plug lid in a closed operational position.

FIG. 10 is a top plan view of the drink container of FIG. 9 with the plug lid in the closed operational position.

FIG. 11 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the closed operational position taken substantially along the line A-A of FIG. 10 .

FIG. 12 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the closed operational position taken substantially along the line B-B of FIG. 10 .

FIG. 13 is a top perspective view of the drink container of FIG. 9 with the plug lid in an intermediate operational position.

FIG. 14 is a top plan view of the drink container of FIG. 9 with the plug lid in the intermediate operational position.

FIG. 15 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the intermediate operational position taken substantially along the line C-C of FIG. 10 .

FIG. 16 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the intermediate operational position taken substantially along the line D-D of FIG. 10 .

FIG. 17 is a top perspective view of the drink container of FIG. 9 with the plug lid in a closed operational position.

FIG. 18 is a top plan view of the drink container of FIG. 9 with the plug lid in the closed operational position.

FIG. 19 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the closed operational position taken substantially along the line E-E of FIG. 10 .

FIG. 20 is a cross-sectional view of the drink container of FIG. 9 with the plug lid in the closed operational position taken substantially along the line F-F of FIG. 10 .

FIG. 21 is a partial cross-sectional, elevational exploded view of the drinking container of FIG. 9 taken substantially along the line A-A of FIG. 10 .

FIG. 22 is a partial cross-sectional, elevational exploded view of the drinking container of FIG. 9 taken substantially along the line B-B of FIG. 10 .

FIG. 23 is a top perspective exploded view of the drink container of FIG. 9 .

FIG. 24 is a bottom perspective exploded view of an upper member of a seal assembly of the drink container of FIG. 9 .

FIG. 25 is a bottom perspective exploded view of a lower member of the seal assembly of the drink container of FIG. 9 .

Detailed description

A drinking vessel or drink container 10 in accordance with the present embodiment is shown in FIGS. 1-8 . The drink container 10 includes a substantially cylindrical body 12 and a lid 14 . The illustrated body 12 has a double wall construction for improved thermal insulation, using an inner body 16 positioned and secured within an outer body 18 . In other embodiments not shown, a single wall construction may be used.

The inner body 16 has a lower inner body portion 20 and an upper inner body portion 22 forming a hollow interior chamber 19 . The outer body 18 has a lower outer body portion 24 and an upper outer body portion 26 . A drinkable liquid (not shown) may be stored in the lower inner body portion 20 when the drink container 10 is in an upright position. The upper inner body portion 22 defines an interior fluid passageway 28 having a longitudinal axis 29 , and an upper end opening 30 at an upper end of the body 12 through which the liquid stored in lower inner body portion 20 may flow for drinking or pouring when the drink container 10 is sufficiently tilted. An upper end portion 32 of the upper inner body portion 22 and an upper end portion 34 of the upper outer body portion 26 are joined at their upper ends to define a drinking lip 36 at the upper end of the body 12 which the lips of a user may be placed for drinking the liquid stored in lower inner body portion 20 when the drink container 10 is sufficiently tilted. A handle 37 is attached to the body 12 by a ring portion 37 A which extends about the upper outer body portion 26 to facilitate the user holding the drink container 10 .

The upper inner body portion 22 has an interior, circumferentially extending body inward protrusion or body ridge 38 projecting inward within the fluid passageway 28 . The body ridge 38 extends continuously about the circumference of the upper inner body portion 22 . The body ridge 38 has a circumferentially extending upper wall portion 38 A which slopes downward in the inward direction, and a circumferentially extending lower wall portion 38 B which slopes upward in the inward direction. As will be described, the body ridge 38 serves as a stop to support the lid 14 when within the fluid passageway 28 and limit its downward movement within the fluid passageway. In alternative embodiments not illustrated, the body ridge 38 may not be continuous.

The lid 14 is a plug-type closure which is insertable by the user into the fluid passageway 28 through the upper end opening 30 for use of the drink container 10 for storing, transporting and drinking a liquid, and removable therefrom when desired by the user for washing the lid and/or body 12 of the drink container. The lid 14 may be operated to move between three states, a closed and securely retained state as shown in FIGS. 1, 1A, 1B and 1C , an opened but retained state as shown in FIGS. 2, 2A, 2B and 2C , and an opened and removable state as shown in FIGS. 3, 3A, 3B, 3C, 4 and 5 . In the closed and securely retained state shown in FIGS. 1, 1A, 1B and 1C , the fluid passageway 28 is closed so no liquid can be drunk from the drink container 10 and the lid 14 cannot be removed from the body 12 (or inserted into the fluid passageway). In the opened but retained state shown in FIGS. 2, 2A, 2B and 2C , the lid 14 is opened for drinking but retained within the fluid passageway 28 against unintended removal. In the opened and removable state shown in FIGS. 3, 3A, 3B, 3C, 4 and 5 , the lid 14 is opened but not retained within the fluid passageway 28 so as to be removable by the user for filling the lower inner body portion 20 with a liquid or for washing the lid and/or the body 12 . The individual component parts of the drink container 10 are separately illustrated in the exploded views of FIGS. 6, 7 and 8 .

The lid 14 includes an upper seal carrier 40 , a lower seal carrier 42 and a flexible tubular seal 44 . The upper seal carrier 40 has an upper portion 40 A and a smaller diameter lower portion 40 B. The upper portion 40 A of the upper seal carrier 40 is sized to engage and be supported by the body ridge 38 when the lid 14 is inserted by the user into the fluid passageway 28 through the upper end opening 30 , while the lower seal carrier 42 is smaller and sized to pass by the body ridge 38 and reside within the fluid passageway below the body ridge. When the lid 14 is positioned within the fluid passageway 28 , the upper seal carrier 40 , the lower seal carrier 42 and tubular seal 44 are coaxially arranged within the fluid passageway 28 . The upper seal carrier 40 and the lower seal carrier 42 are axially spaced apart and each extend transverse to the longitudinal axis 29 . As will be described in greater detail below, the lower seal carrier 42 is axially movable relative to the upper seal carrier 40 within the fluid passageway 28 .

The tubular seal 44 has the shape of a bellows with a single convolution and may be made of a soft silicon material. The tubular seal 44 has a circumferential upper end portion 46 sealingly attached to the upper seal carrier 40 and a circumferential lower end portion 48 sealingly attached to the lower seal carrier 42 . The tubular seal 44 has a thin perimeter sidewall 44 A and a hollow interior space 44 B located within the perimeter sidewall and extending the full length of the tubular seal upper and lower end portions 46 and 48 . The interior space 44 B spans a substantial portion of the interior cross-sectional area of the fluid passageway 28 , in the illustrated embodiment when in the opened and removable state shown in FIGS. 3, 3A, 3B, 4 and 5 , the interior space spans approximately 93% of the interior cross-sectional area of the fluid passageway, and preferably spans at least 50% of the interior cross-sectional area of the fluid passageway. While the tubular seal 44 is illustrated as having a generally tubular shaped flexible perimeter sidewall 44 A and the hollow interior space 44 B as extending fully between its upper and lower end portions 46 and 48 , the sidewall and interior space may have other shapes and configurations.

When the lid 14 is positioned within the within the fluid passageway 28 , the upper portion 40 A of the upper seal carrier 40 is positioned above and in engagement with an upper portion of the body ridge 38 of the upper inner body portion 22 of the body 12 , which supports the upper seal carrier and prevents further downward movement of the lid within the fluid passageway. When the lid 14 is so positioned, a perimeter sidewall 50 of the upper portion 40 A of the upper seal carrier 40 is positioned adjacent to an upper interior wall surface portion 52 of the upper inner body portion 22 , except for a drink dispensing aperture 54 formed by an inwardly recessed region at the perimeter of the upper portion of the upper seal carrier through which liquid may pass for drinking when the drink container 10 is sufficiently tilted and the lid is in the opened but retained state as shown in FIGS. 2, 2A, 2B and 2C , or the opened and removable state as shown in FIGS. 3, 3A, 3B and 3C (although when in the opened and removable state the lid is not securely retained within the fluid passageway).

When the lid 14 is positioned within the fluid passageway 28 with the upper portion 40 A of the upper seal carrier 40 positioned above and engagement with the body ridge 38 , a perimeter sidewall 56 of the lower seal carrier 42 is positioned inward away from a lower interior wall surface portion 58 of the upper inner body portion 22 . This forms a circumferentially extending, perimeter fluid flow pathway 60 between the perimeter sidewall 56 and the lower interior wall surface 58 through which liquid may pass for drinking when the drink container 10 is sufficiently tilted.

The lower portion 40 B of the upper seal carrier 40 has a perimeter sidewall 62 and is positioned within an upper edge portion 64 of the upper end portion 46 of the tubular seal 44 . The perimeter sidewall 62 of the lower portion 40 B of the upper seal carrier 40 has a circumferential extending outward facing protrusion 66 over which the upper edge portion 64 of the tubular seal 44 extends to position the protrusion 66 in a circumferentially extending inward facing groove 68 of the upper edge portion to sealingly secure the upper edge portion to the upper seal carrier 40 .

The perimeter sidewall 50 of the upper portion 40 A of the upper seal carrier 40 has a circumferentially extending outward facing groove 70 in which a circumferentially extending seal 72 is positioned to provide a fluid-tight seal between the upper seal carrier 40 and the upper interior wall surface portion 52 of the upper inner body portion 22 when the lid 14 is positioned within the within the fluid passageway 28 , except at the drink dispensing aperture 54 .

The lower seal carrier 42 is positioned at least partially within a lower edge portion 74 of the lower end portion 48 of the tubular seal 44 . The perimeter sidewall 56 of the lower seal carrier 42 includes a circumferentially extending outward facing slot 76 in which an end portion 75 of the lower edge portion 74 is positioned and secured to sealingly secure the lower edge portion 74 to the lower seal carrier 42 .

A midportion 77 of the tubular seal 44 has a circumferentially, outwardly projecting extending bulge which is mostly positioned below the upper seal carrier 40 and the body ridge 38 . The midportion 77 has a circumferentially extending upper wall portion 77 A and a circumferentially extending lower wall portion 77 B. When the midportion 77 is compress by moving the lower seal carrier 42 upward to be closer to the upper seal carrier 40 , as will be described in greater detail below, the upper and lower wall portions 77 A and 77 B move closer together, and the upper wall portion 77 A moves closer to the body ridge 38 . In the closed and securely retained state shown in FIGS. 1, 1A, 1B and 1C , the upper wall portion 77 A is pressed against the body ridge 38 to provide a fluid-tight seal therebetween and close the fluid passageway 28 , thus preventing fluid stored in the lower inner body portion 20 from flowing upward through the fluid pathway 60 to the drink dispensing aperture 54 even when the drinking container is tilted. In the illustrated embodiment, the upper wall portion 77 A presses against the lower wall portion 38 B of the body ridge 38 .

A connector member 78 has an exteriorly threaded base portion 79 which is threadably received in an interiorly threaded central opening 80 of the lower seal carrier 42 for axial movement of the connector member with axial movement of the lower seal carrier. The connector member 78 has a lifter member 82 located inward of the perimeter sidewall 44 A of the tubular seal and within the interior space 44 B, and which projects axially upward from the lower seal carrier 42 and through a central aperture 84 in the upper seal carrier 40 . An upper end portion 86 of the lifter member 82 extends above the upper seal carrier 40 and has a transverse lifter member bore 88 .

A cam member 90 is positioned about the upper seal carrier 40 and has a pair of spaced apart cam portions 92 and 94 located at a lower end thereof. The upper end portion 86 of the lifter member 82 is positioned between the cam portions 92 and 94 . The cam portions 92 and 94 each have a transverse cam portion bore 96 which axially aligns with the lifter member bore 88 . A pivot pin 98 extends through the cam portion bores 96 and the lifter member bore 88 to rotatably attach the cam member 90 to the upper end portion 86 of the lifter member 82 to permit rotation of the cam member 90 about a transverse axis of rotation 100 .

The cam member 90 has a handle portion 102 to which the cam portions 92 and 94 of the cam member are rigidly attached for rotation with the handle portion. Each of the cam portions 92 and 94 has a first cam 104 and a second cam 106 extending in opposite directions away from the handle portion 102 transverse to the pivot pin 98 , with both of the first cams 104 extending to one side of the handle portion and both of the second cams 106 extending to an opposite side of the handle portion. The first cam 104 is longer than the second cam 106 to provide a greater amount of lift than the second cam. The handle portion 102 is rotatable about the pivot pin 98 between a first rotational/operational position shown in FIGS. 1, 1A, 1B and 1C , a second rotational/operational position shown in FIGS. 2, 2A, 2B and 2C , and a third rotational/operational position shown in FIGS. 3, 3A, 3B and 3C . The third rotational/operational position of the handle portion 102 is located between the first and second rotational/operational positions of the handle portion. Rotation of the handle portion 102 directly produces rotation of the first and second cams 104 and 106 . The handle portion 102 projects away from the cam portions 92 and 94 and provides a grip for grasping by a user for rotation of the cam member 90 about the pivot pin 98 and rotation of the handle portion 102 between its first, second and third rotational/operational positions. The handle portion 102 has a central aperture 108 sized to allow at least one finger of the user to fit therethrough to facilitate grasping of the handle portion for rotation of the cam member 90 or for removal of the lid 14 from the fluid passageway 28 and insertion of the lid into the fluid passageway.

When the handle portion 102 is in the third operational position, as best illustrated in FIGS. 3B and 3C , with the handle portion 102 extending straight upward, the first and second cams 104 and 106 extend laterally outward in opposite directions and transverse to the longitudinal axis 29 and are oriented generally parallel to an upper surface 110 of the upper seal carrier 40 . In this position, the lower seal carrier 42 is at a maximum distance positioned below the upper seal carrier 40 such that the flexible tubular seal 44 is axially stretched out with the midportion 77 having a width which permits it to be easily moved past the body ridge 38 of the upper inner body portion 22 of the body 12 , both when removing the lid 14 from the fluid passageway 28 and when inserting the lid 14 into the fluid passageway. In this position, the lid 14 is opened but not retained within the fluid passageway 28 so as to be removable by the user for filling the lower inner body portion 20 with a liquid or for washing the lid and/or the body 12 .

When the handle portion 102 is rotated from the third operational position to the first operational position, with the handle portion 102 rotated to extend to the left (as viewed in FIG. 1B ), as best illustrated in FIG. 1B the longer first cams 104 have been rotated counter-clockwise to engage the upper surface 110 of the upper seal carrier 40 (which rests atop the body ridge 38 ) and apply an upward axial force on the lifter member 82 which transmits that upward lifting force to the lower seal carrier 42 and moves the lower seal carrier closer to the upper seal carrier 40 . During this movement the shorter second cams 106 are out of contact with the upper surface 110 . This results in flexing of the tubular seal 44 radially outward (transverse to the longitudinal body axis 29 ), thus increasing the lateral width of the outward bulge of the midportion 77 of the tubular seal sufficiently and moving the midportion into fluid-tight sealingly engagement with a lower portion of the body ridge 38 of the upper inner body portion 22 of the body 12 , creating a fluid-tight compression seal therewith. In this position, the lower seal carrier 42 is at a minimum distance positioned below the upper seal carrier 40 such that the flexible tubular seal 44 is compressed. As a result, the lid 14 is closed and securely retained within the fluid passageway 28 so no liquid can pass fully through the fluid passageway 28 and be drunk from the drink container 10 , and the lid 14 cannot be removed from the body 12 . If the handle portion 102 was moved to the first operational position with the lid 14 removed from the fluid passageway 28 , the expanded midportion 77 of the tubular seal 44 would prevent it from being reinserted into the fluid passageway.

When the handle portion 102 is rotated from third operational position to the second operational position, with the handle portion 102 rotated to extend to the right (as viewed in FIG. 2B ), as best illustrated in FIG. 2B the shorter second cams 106 have been rotated clockwise to engage the upper surface 110 of the upper seal carrier 40 (which rests atop the body ridge 38 ) and apply an upward axial force on the lifter member 82 which transmits that upward lifting force to the lower seal carrier 42 and moves the lower seal carrier closer to the upper seal carrier 40 . During this movement the longer first cams 104 are out of contact with the upper surface 110 . This results in flexing of the tubular seal 44 radially outward (transverse to the longitudinal body axis 29 ), thus increasing the lateral width of the outward bulge of the midportion 77 of the tubular seal, but not sufficiently that it sealingly engages the lower portion of the body ridge 38 of the upper inner body portion 22 of the body 12 and thus does not close off the flow of liquid through the fluid passageway 28 . In this position, the lower seal carrier 42 is at a middle distance positioned below the upper seal carrier 40 , which is greater than the minimum distance resulting when the handle portion 102 is in the first operational position, but less than the maximum distance resulting when the handle portion is in the third operational position. As a result, the flexible tubular seal 44 is only partially compressed compared to when the handle portion 102 is in the first operational position. The partial compression of the tubular seal 44 causes the midportion 77 to move outward sufficiently that it will engage the lower portion of the body ridge 38 to inhibit removal of the lid 14 from within the fluid passageway 28 and prevent unintended removal should the lid experience an axial force moving tending to move it toward the upper end opening 30 of the upper inner body portion 22 , while still permitting drinking liquid from the drink contain 10 . For example, when the handle portion 102 is in the second operational position, if during drinking or carrying the drink container 10 it is sufficiently tilted or upwardly jarred such that an axial force is exerted on the lid 14 that would otherwise cause the lid to move out of the fluid passageway 28 , before doing so the expanded midportion 77 of the tubular seal 44 will move into engagement with the lower portion of the body ridge 38 and thereby prevent the unintended lid removal. Depending on the extent of compression of the tubular seal 44 selected for the design, the user might still be able to apply enough intentional upward force on the handle portion 102 to flex the midportion 77 inward sufficiently to result in removal of the lid 14 from the fluid passageway 28 .

The three position lid 14 allows the user to drink from the drinking container 10 while at the same time keeping the lid securely and safely retained within the fluid passageway 28 against unintended lid removal, and to both open the fluid passageway for drinking and close the fluid passageway for transport without having to remove the lid from or reinsert the lid into the fluid passageway. These operations and features are accomplished simply by rotating the handle portion between its three operational positions without removal and reinsertion of the lid 14 .

An alternative embodiment of a drinking vessel or drink container 200 in accordance with the present embodiment is shown in FIGS. 9-25 . The drink container is shown in a closed state in FIGS. 9-12 . The drink container 200 includes a substantially cylindrical body 212 and a lid 214 . As discussed above for the body 12 , the body 212 may have a double wall construction for improved thermal insulation, using an inner body positioned and secured within an outer body. In this illustrated alternative embodiment, the body 212 has a single wall construction, which in a double wall construction drink container would serve as the inner body.

The body 212 has a lower body portion 220 and an upper body portion 222 defining a hollow interior chamber 218 . A drinkable liquid (not shown) may be stored in the lower body portion 220 when the drink container 200 is in an upright position. As illustrated in FIGS. 11 and 12 , the upper body portion 222 has an interior fluid passageway 228 with a longitudinal axis 229 and an upper end opening 230 at the upper end of the upper body portion 222 through which the liquid stored in lower body portion 220 may flow for drinking or pouring when the drink container 200 is sufficiently tilted. An upper end portion 232 of the upper body portion 222 defines a drinking lip at the upper end of the body 212 on which the lips of a user may be positioned for drinking the liquid stored in lower body portion 220 when the drink container 200 is sufficiently tilted. The body 212 may include a handle 216 to facilitate the user holding the drink container 200 .

The upper body portion 222 has an interior, circumferentially extending inward protrusion or body ridge 238 projecting inward within the fluid passageway 228 . The body ridge 238 extends continuously about the circumference of the upper body portion 222 . The body ridge 238 has a circumferentially extending upper wall portion 238 A which slopes downward in the inward direction, a circumferentially extending lower wall portion 238 B which slopes upward in the inward direction, and a circumferentially extending vertical middle wall portion 238 C positioned between the upper and lower wall portions. As will be described, the body ridge 238 serves as a stop to support the lid 214 when within the fluid passageway 228 and limit downward movement of the lid within the fluid passageway, and also as an engagement surface the lid grips when within the fluid passageway to inhibit its unintentional upward movement within the fluid passageway. In alternative embodiments not illustrated, the body ridge 238 may not be continuous.

The upper body portion 222 further has an interior, inwardly opening, circumferentially extending upper body recess 240 within the fluid passageway 228 , at a location above the body ridge 238 and below the upper end opening 230 , which extends continuously about the internal circumference of the upper body portion and serves as a seal seat, as will be described in greater detail below. An upper edge wall 242 of the recess 240 protrudes inwardly into the fluid passageway 228 .

The lid 214 is a plug-type closure which is insertable by the user into the fluid passageway 228 through the upper end opening 230 for use of the drink container 200 for storing, transporting and drinking a liquid, and is removable therefrom when desired by the user for washing the lid and/or body 212 of the drink container. The lid 214 may be operated to move between two states, i.e., a closed and securely retained first state as shown in FIGS. 9-12 , and an opened and retained, but easily removable second state as shown in FIGS. 17-20 . FIGS. 13-16 show the lid 214 in an intermediate position through which the lid moves when transitioning between the first (closed) state and the second (opened) state, as will be described in more detail below.

In the first (closed) state the lid 214 is closed and securely retained within the fluid passageway 228 so no liquid can be drunk or spilled from the drink container 200 and the lid cannot be removed from the body 212 (or inserted into the fluid passageway). In the second (opened) state the lid 214 is opened for drinking and retained within the fluid passageway 228 against unintended removal, but with sufficient upward force applied by the user, the lid is removable for filling the lower body portion 220 with a liquid or for washing the lid and/or the body 212 . The individual component parts of the drink container 200 are separately illustrated in the exploded views of FIGS. 21-23 and the component views of FIGS. 24 and 25 .

The lid 214 includes a seal assembly 244 having an upper member 246 , a lower member 248 and a stretchable and resilient ring seal 250 . In the illustrated embodiment the ring seal 250 is an O-ring but other shapes of ring-type seals may be used. The upper member 246 has a circumferentially extending, perimeter upper member portion 246 A, a smaller diameter circumferentially extending, perimeter lower member portion 246 B and a circumferentially extending, perimeter middle member portion 246 C positioned between the upper and lower member portions. A drink dispensing aperture 247 formed by an inwardly recessed region of the perimeter upper member portion 246 A is provided for liquid to pass for drinking when the drink container 200 is sufficiently tilted and the lid is in its second (opened) state. The perimeter lower member portion 246 B has a circumferentially extending vertical, outward facing perimeter wall 252 , and the perimeter middle member portion 246 C has a circumferentially extending, outward facing perimeter smooth ramp wall 254 which slopes upward in the outward direction with the shape of a conical wall section.

The perimeter lower member portion 246 B of the upper member 246 has a smaller diameter than the perimeter upper member portion 246 A and is sized to pass by the upper edge wall 242 of the recess 240 to position the wall 254 of the perimeter middle member portion 246 C inward of the recess. The ring seal 250 is shown in FIGS. 19 and 20 with the lid 214 in the second (opened) position mounted on and extending about the wall 252 of the perimeter lower member portion 246 B of the upper member 246 at a vertical position directly opposite the recess 240 and inward of the recess. In this position the ring seal 250 is in an initial perimeter position and has an initial interior diameter/perimeter the same size as the exterior diameter/perimeter of the wall 252 and an initial exterior diameter/perimeter. As will be described below, the upper member 246 is movable upward and downward by the user relative to the lower member 248 , and during that movement the ring seal 250 is movable upward and downward relative to the upper member 246 between the wall 252 of the perimeter lower member portion 246 B and positions on the ramp wall 254 of the perimeter middle member portion 246 C.

The lower member 248 of the lid 214 has a circumferentially extending, perimeter upper member portion 248 A, and a smaller diameter circumferentially extending, perimeter lower member portion 248 B. The perimeter upper member portion 248 A of the lower member 248 is sized to engage and be supported by the upper wall portion 238 A of the body ridge 238 when the lid 214 is inserted by the user into the fluid passageway 228 through the upper end opening 230 to support the lower member 248 when within the fluid passageway and limit its downward movement. In the illustrated embodiment, the perimeter upper member portion 248 A has four circumferentially extending, spaced-apart perimeter wall sections 248 A- 1 , 248 A- 2 , 248 A- 3 and 248 A- 4 , each sized and positioned to engage and be supported by the upper wall portion 238 A of the body ridge 238 when the lid 214 is inserted by the user into the fluid passageway 228 , as best shown in FIGS. 12, 16 and 20 .

The perimeter lower member portion 248 B has a smaller diameter than the perimeter upper member portion 248 A and is sized to pass by the upper wall portion 238 A of the body ridge 238 and reside within the fluid passageway 228 opposite the middle wall portion 238 C of the body ridge. In the illustrated embodiment, the perimeter lower member portion 248 B has four circumferentially extending, spaced-apart perimeter wall sections 248 B- 1 , 248 B- 2 , 248 B- 3 and 248 B- 4 , each having a circumferentially extending groove 256 , within which is positioned a friction member 258 sized to frictionally engage the middle wall portion 238 C with sufficient frictional force to resist upward movement of the lower member 248 as the lid 214 is operated to move between its first (closed) and second (opened) states, and when the drink container 200 is tilted for drinking. However, the frictional force is not so great as to prevent the user from manually moving the lower member 248 and the entire lid 214 upward for removal of the lid from the body 212 for filling the lower body portion 220 with a liquid or for washing the lid and/or the body. The spaced-apart perimeter wall sections 248 B- 1 , 248 B- 2 , 248 B- 3 and 248 B- 4 of the perimeter lower member 248 B are positioned immediately below and coextensive with the spaced-apart perimeter wall sections 248 A- 1 , 248 A- 2 , 248 A- 3 and 248 A- 4 of the perimeter upper member portion 248 A.

Inward of the perimeter upper member portion 248 A, the lower member 248 has four circumferentially distributed apertures 260 , each sized to slidably received one of four correspondingly positioned vertically oriented, elongated guide members 262 of the upper member 246 when the upper and lower members 246 and 248 are assembled. The slidable positioning of the guide members 262 in the apertures 260 prevents rotation of the upper member 246 relative to the lower member 248 as the upper member is moved upward and downward by the user relative to the lower member to move the lid 214 between its first (closed) and second (opened) states.

To provide for upward and downward movement of the upper member 246 relative to the lower member 248 , the upper member has a central collar portion 264 with an axially oriented opening 266 having a smooth interior sidewall 268 . The lower member 248 of the lid 214 also has a central collar portion 270 with an axially oriented opening 272 , in axial alignment with the opening 266 of the upper member 246 . The opening 272 has an interior wall with a screw thread 274 .

The lid 214 further includes an axially oriented, manually operable actuator member 276 with a manually gripable handle 278 at an upper end thereof and with a lower end portion 280 exteriorly threaded with an exterior screw thread 282 matching the threading of the interior screw thread 274 of the opening 272 of the lower member 248 . When the lid 214 is assembled, the actuator member 276 extends through the smooth sidewall opening 266 of the upper member 246 and the threaded opening 272 of the lower member 248 which threadably receives the threaded lower end portion 280 of the actuator member. An upper portion of the actuator member 276 , below the handle 278 and above the threaded lower end portion 280 , has a first circumferentially extending groove 284 sized to receive a ring seal 286 . When the lid 214 is assembled, the seal 286 is located within the opening 266 of the upper member 246 and in fluid-tight sealing engagement with the smooth interior sidewall 268 .

A second circumferentially extending groove 288 is provided in the lower end portion 280 of the actuator member 276 , below the first groove 284 and above the screw thread 282 of the lower end portion, and sized to receive a first C-clip 290 . When the lid 214 is assembled, the first C-clip 290 is located below the collar portion 264 of the upper member 246 to allow rotational movement of the actuator member relative to the upper member 246 and to carry the upper member upward with the actuator member when the actuator member moves upward relative to the lower member 248 . The handle 278 of the actuator member 276 has a circumferentially extending lower end wall 292 positioned above the first groove 284 and in sliding engagement with an upper end 266 A of the collar portion 264 of the upper member 246 when the lid 214 is assembled to allow rotational movement of the actuator member relative to the upper member 246 and to trap the collar portion 264 between the end wall and the first C-clip 290 . In such manner the actuator member 276 and the upper member 246 travel upward and downward together, but the actuator member is rotatable relative to the upper member to control the position of the upper member along the longitudinal axis 229 relative to the lower member 248 .

A third circumferentially extending groove 294 is provided in the lower end portion 280 of the actuator member 276 below the screw thread 282 of the lower end portion, and sized to receive a second C-clip 296 . When the lid 214 is assembled, the second C-clip 296 is located below the collar portion 270 of the lower member 246 to allow rotational movement of the actuator member 276 relative to the lower member 248 while limiting the upward movement of the actuator member within the collar portion 270 resulting from rotation of the actuator member.

The first C-clip 290 and the second C-clip 296 are axially spaced apart to allow sufficient axial movement of the actuator member 276 , and hence the upper member 246 which moves with the upper member, relative to the lower member 248 to move the lid 214 fully between its first (closed) and second (opened) states resulting from rotation of the actuator member 276 relative to the lower member 248 . When the actuator member 276 is rotated in a first rotational direction (counter-clockwise when viewed from above in the illustrated embodiment), the threaded engagement of the actuator member screw thread 282 with the interior screw thread 274 of the lower member moves the upper member 246 upward relative to the lower member 248 and hence moves the lid 214 toward the its second (opened) state shown in FIGS. 17-20 , and when the actuator member is rotated in an opposite second rotational direction (clockwise), the threaded engagement of the actuator member screw thread with the interior screw thread of the lower member moves the upper member downward relative to the lower member and hence moves the lid 214 toward the its first (closed) state shown in FIGS. 9-12 . The total axial movement of the upper member 246 relative to the lower member 248 being no greater than the axial spacing between the first and second C-clips 290 and 296 .

When the lid 214 is positioned within the fluid passageway 228 , the upper member 246 , the lower member 248 , the ring seal 250 and the actuator member 272 are coaxially arranged within the fluid passageway and in axial alignment with the longitudinal axis 229 . Since the body 212 in the illustrated embodiment is cylindrical, the upper member 246 and lower member 248 are generally disk shaped to correspond to the interior shape of the interior fluid passageway 228 within which the lid 214 is positioned.

The description continues in the full USPTO document.
